2016-11-29

Filling Machine: Semi automatic stand up bag spout filling machine with different nozzles Abfuellmaschine fuer Fluessigkeit

Filling Machine: Semi automatic stand up bag spout filling machine with different nozzles Abfuellmaschine fuer Fluessigkeit

Semi automatic stand up bag spout filling machine with different nozzles Abfuellmaschine fuer Fluessigkeit

used paint filling equipment for sale aerosol paint filling equipment thick paint filler

Quick Details

Type:
Filling Machine
Condition:
New

Packaging Type:
Plywooden case
Packaging Material:
Wood


Driven Type:
Pneumatic
Voltage:
220V/50HZ


Place of Origin:
Guangdong China (Mainland)
Brand Name:
Topcn


Dimension(L*W*H):
167*51*51cm
Weight:
50kg


After-sales Service Provided:
No overseas service provided
Name:
vertical cream and liquid filling machine


Material:
stainless
temperature:
room degree


Filling material:
not very high vosicosity
Warranty:
12 Months
Semi automatic pouch bags filling machine for liquid laundry detergent pneumatic filler
Semi automatic stand up bag spout filling machine with different nozzles Abfuellmaschine fuer Fluessigkeit






















 model  Filling volume  Air consumption  Net weight  Dimension
 TSFM01-120  10-120ml  30L/min  22kgs  L55*W49*H122(cm)
 TSFM01-250  25-250ml  44L/min  25kgs  L55*W49*H122(cm)
 TSFM01-500  50-500ml  87L/min  28kgs  L55*W49*H122(cm)
 TSFM01-1000  100-1000ml  160L/min  36kgs  L55*W49*H122(cm)
 TSFM01-2500  250-2500ml  300L/min  60kgs   L55*W49*H200(cm)


water---honey sugar---acid cheese---fruit juice---shower gel---gear oil
liquid coffee---ink---eye shadow fluid---tea---shampoo---glue---food/paint
washing hand fluid---cream---milk---liquid soap---butter & margarine
syrup---plant oil---cooking oil---paste---face mask---detergent sauce---salad
butter & margarine---ketchup---jam---honey











2016-10-26

How to operate Filling machine for honey, sauce paste, oil, detergent shampoo,hand washing,wave liquid,syrup


Model
PAFM-8
Filling range 10-120 ml
Capacity 20-30 bottles/min
Accuracy ±0.5%
Motor power 0.24 Kw
Total power 0.75 Kw
Working voltage 220 V
Conveyor width 114 mm
Stainless steel 304
Hopper volume 40 L
packaging machine for perm lotion Detail Pictures

Working Principle
1)Using the touch screen to control the whole machine,including the speed of the conveyor ,the filling volume etc.
2)Trough bottle loading machine make the bottles get into the conveyer belt one by one .
3)The bottle go into the model trun table ,when sensor feel it ,automatic filling .
4)The cup loading machine make the cups along the track move one by one through shaking ,when sensor feel the bottle ,automatic loading the cover on the bottle.
5)Last ,automatic capping .
Option
1. Variable filling device ( for Liquid,Ointment, Powder, Granule, etc)
2. Bottle star wheel for another bottle size
3. Automatic air spray bottle cleaning station
4. Perfume bottle automatic steel ball dropping station
5. Automatic Plug Feeder and Insert Station
6. Automatic Cap Feeder and Insert Station (for one cap size)
7. In-feed and out- feed turn table
8. All contact parts made of Stainless Steel #316.
9. Two lines bottles in-feed, two nozzles filling, Double capacity
10. Thermal Seal for bottle mouth

used packaging machine Instruction of operate interface:
At first, check the circuit and steam are connected or not. Then open the chief switch, enter the main interface, enter the filling machine operating system.

Click“中文”/ENGLISH, and enter below interface:




Volume settingfor 1-8# nozzles
Set volume as per real filling volume,if the filling volume is 500ml,the real volume from filling nozzle(1-8#) will be a little difference, if the real volume from nozzle 1# is 502mlyou should set the volume number a little low,around 498ml. Like this,pls set volume of 1-8# as same as this way.
Current volumeshowing filling volume current, the numericalis be showed automatic, can not be change.
Current speedshowing filling speed current, the numericalis be showed automatic, can not be change.
Please enter “Manual” interface,


Machine adjustment
A:Adjust conveyor according to the width of the products, the bottle moving cannot too tight or too loose, can twist the five-star handle, adjust it freely.


B:Open the conveyer, slow down speed, ,fixed the back clip bottle cylinder on the slippery course of Clip bottles cylinder, make the back clip bottle cylinder manually. Press "After bottle" button, the back clip bottle cylinder is start. Blocking the bottle to continue move.
The speed of Cylinder blocking bottles and cylinder can be adjusted by the two one-way regulator on cylinder.As Below,all the below cylinder speed are adjusted with this method.
C:put 8 pieces bottle on the conveyor, and fixed the position of front clip bottle cylinder on the sliding rail.then star the front clip bottle cylinder“Ago bottle”blocking the bottles.


D:
adjust the clip mouth position for filling mouth.
fixed the front clip bottles on sliding rail by 8pcs bottles, then turn on the cylinder of front clip,and blocking the bottles.
E:Adjust the clip mouth position for filling mouth.fixed the 8pcs of bottles by device of front and back clip bottles, use the tool to adjust the clip block as shown in figure position, all different bottle mouth need to be adjusted again. press "Nip" manual clip bottle, can be used to test the position adjustment is correct or not.

F:Adjust the filling mouth position,Adjust the filling mouth position according to the distance of bottles
G:Adjust the height of filling mouth Use the black hand wheel adjust to the filling mouth on the bottle position .Then press "Nozzle UP down" by manual testing, until adjust to the proper position.
H:Adjust front and back position for device of meet material.
The above parts were adjusted wellnow press "nozzle up and down"neck holderfor testing.
1-8# filling ,check they work well or not by press the above button.
Belt":for turn on or off the conveyor
Fault reset":if there is any faults or crash when filling, press this key for reset.
Reset: press this key and the machine back original
Limit up":press this key, servo will work up, then loose finger, servo stop work.
Limit down":press this key, servo will work to down, then loose finger, servo stop work.
After manual adjustment, enter below interface:

Servo motor filling machine adopt three speed setting separately,different material different speed,thick material with high speed, the maximum speed numerical is 3000. Material with big foam should with low speed.
Filling capacitythese three numerical are corresponding with numerical of speed. “1 speed” corresponding with “1 capacity” , like this, “2 speed” corresponding with “2 capacity”, “3 speed” corresponding with “3 capacity”.
Countfilled bottle quantity.
Belt speed:this numerical for setting conveyor speed,Numerical representative is HZ,Maximum is 50HZ.
Now speedthe numericalis be showed automatic, can not be change.
Filling Clear: Zero clearing managepress this keythe previous counter is zerocount again.
ESC speedmachine finish working, back to speed adjustment.
I:Adjustment for feeding pump

Turn on the pump switch,machine check the level in tank automatic, the pump will work and feeding material automatic when lack material.
J:Press Emergency Stop when there is sudden case with the working machine, stop machine urgency. Pull out the Emergency switch when you need run machine again.

Enmergency stop
K:All adjustment finishedexit the manul adjust interface, enter the filling state.suction feeding pump will feeding material automatic when filling automaticThe pump will suck material automatic when the inside material in the hopper can not reach a certain position, put enough bottles in the front of electric eye for sensor bottle. Then manul response the front electric eye,the machines will be entered normal work state, continue to put the bottles in front .
Senosr
L: Bottle sensor adjustment:(Generally, it was adjusted well before leave factory)
If sensor can not detect the bottle under normal working,the amplifier in below photo not shin,please adjust the knob on the sensor, if pass 8pcs of bottles, and detect 9 times, it means the sensor too sensitive, please adjust it a little tiny. reverse, if pass 8pcs of bottles, and detect 8 times less, it means the sensor too insensitive, please adjust it a little more.adjust the detected quantity agrees with bottles quantity. Turn on the conveyor at first, do not filling, testing more times use empty bottles,then start formal filling, for prevent fault with sensor testing, and material spray out.
M:Maintane machine
Cleaning machine:use raw water for normal cleaning. if need cleaning exhaustiveneed take apart the three-way valve, charging barrel from machine for cleaningHopper can be cleaned by the next purge valve, Then the water is flow out through this valve.the whole machine can't allow water flows into the electricity box. Prevent electric appliance product burn out.

keep the machine be sanitary
Package of foam packaging machine:




2016-10-23

Thailand customer orders TSFM01-500 semi automatic vertical self suction liquid filler small packaging machine liquid filling equipment


Thanks for our Thailand customer who placed on conveyor belt for theirTSFM01-500 semi automatic vertical self suction liquid filler small packaging machine liquid filling equipment machine requirement , we soon arrage production.Within one week we finished the 25-250ml liquid small package filling.TSFM01-25-250ml model payment remittance as below:


2016-10-10

6 heads linear filling machine honey bottles inline screw capping machinery máquina de llenado miel


6 heads linear filling machine honey bottles inline screw capping machinery máquina de llenado miel is specially made for all kinds of viscosity materials, such as jam, chocolate paste,peanut butter, honey, butter, Mayonnaise, ketchup etc. And all kinds of jam with small fruit pieces  filling in bottles . By adjusting the position pump, it can fill all of the bottles in one filling machine, with quick speed and high precision.Use automatic piston pump executive filling.
Main technical parameters of 6 heads linear filling machine honey bottles inline screw capping machinery máquina de llenado miel
HS code----8422303090
Output power2000W
VoltageAC220V/380,50/60HZ
Machine weight ------800kg
Productive Capacity----- 20-80BPM(customized)
Machine size----1300*900*1550mm
Filling Range-----100-1000ml (Customer made available)
Control Style------PLC control
Time adjust--------electronic adjust
Packaging------------wooden case packaging
FEATURES
1.Fully in accordance with the ISO standard production and passed CE certification
2.It is easy cleaning and disinfection by the unique design
3.It is applicable for various viscosity liquid ,high precision.
4.We can add or decrease the filling speed according to your needing
5.Customers can determine the number of filling and filling heads by customer's demand
6.The parts which contact material are SUS316L stainless steel and others are SUS304 stainless steel
7.PLC control system, color touch screen display, control motor speed automatically
Filling  for honey, sauce paste, oil, detergent shampoo,hand washing,wave liquid,syrup

Our filling machine is suitable filling honey, sauce paste, cooking oil,essential oil, detergent shampoo,hand washing,lubricating oil,wave liquid,syrup, water etc.
Technology parameters:
Filling capacity
25-250ml,50-500ml,150-1000ml,500-2500ml(different specifications can choose to order)
Filling speed:50-80 bottle / min (refers to the 50-500ml range of 6 calculations)
Filling accuracy<±1%
Power Supply:380V 50HZ
Pressure(MPa):0.5-0.7
Outline dimension(mm):2000*870*1900
Weight(kg):500
This Filler is manufactured with heavy duty 304 stainless steel, high quality tig-welded tube frame and is available with 1 to 16 Fill Heads. It also comes standard with PLC controls and color touch screen HMI, a stainless steel reservoir, and Pneumatic Indexing Gates, plus many more features. Further options are available for even more versatility. Overflow Fillers are commonly used for filling beverages and other thin products, especially where foam or bottle inconsistency might be an issue.
Applications of liquid detergent filling machine
Our fillers are most commonly applicable for pharmaceutics, daily chemicals, foodstuffs, cosmetics, pesticides and other industrials;
Typical application: used for filling liquidity is good material, such as filling liquid and paste material, such as water, oil, juice, detergent, sauce, salad, butter, margarine, ketchup, jam, cream, honey, shampoo etc.
Suitable for various packing such as bottle, jar, can, cup, bag, barrels, etc;
Payment & Delivery
* MOQ: 1 Unit
* Port: Shanghai
* Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
* Packaging Material: Paper/Wood
* Packaging Type: Cartons
* Delivery: We’ll arrange delivery within 3 days on the receipt of payment.
We Provide
* Best products and factory price.
* On-time delivery and the shortest delivery time.
* 1-year warranty. If our products cannot function properly within 12 months, we’ll offer spare parts for free; and you need to pay for the delivery.
* OEM and customized service.
* User manuals will go with relative machines.
Service
* QC: All products will be checked before delivery.
* Compensation: If any unqualified product is found, we’ll pay the compensation or send new qualified products to customers.
* Maintenance & Repair: In case of any maintenance or repair need, we’ll help to find out the problem and offer relative guidance.
* Operation Guidance: If you have any problem with operation, please feel free to contact us
automatic edible oil filling capping machine автоматическое заполнение укупорочные машины

This automatic edible oil filling capping machine автоматическое заполнение укупорочные машины  used for filling edible oil such as vegetable oil, salad oil, olive oil and so on.
Automatic controlled by computer PLC, touch screen control panels. Totally enclose form,submergence filling , high measurement accuracy. Compact and perfect feature , liquid cylinder and conduits easy dismount and clean.
It also may suited various figure containers.
The machine is used high-quality stainless steel frames, international famous brand electrical components, also applied to GMP standard requirement.
Details about automatic edible oil filling capping machine автоматическое заполнение укупорочные машины
1, This Automatic Healthy Cooking Oil Filling Machine has compact structure, flawless control system, and is convenient to operate with high grade automatism.
2,All the parts contacting the media are made of high quality stainless steel, able to bear corrosion and easily rinsed
3,Adopts high precision and high speed ration filling valve so that the oil level is exact with loss, ensuring high quality filling.
4,The capping head has constant twisting movement, which ensures capping quality, without damaging caps
5,Adopts high efficiency cap tidying system, with flawless equipment for feeding caps and protecting
6, Needs only to change the pinwheel, bottle entering screw and arched board when changing bottle models, with simple and convenient operation.
7,There is flawless equipment for overload protecting, which can protect effectively machine and operator safety
8,This oil filling and capping machine adopts an electromotive with transducer adjusting speed, and is convenient to adjust productivity.
9,All the main electric elements, transducer, photoelectric switch, near switch, and electric controlling valve are imported to ensure the high quality performance of the whole machine.
10,The control system has functions for auto controlling of oil levels, checking and alarming for cap shortage, and team output counting.
11,All pneumatic components elements are Famous brand-edible oil filler- oil filler -salad oil filler
Current supply : 220V or 380V-50HZ or according to client voltage requirement
Filling nozzle: 6
Power : 1.5KW
Production Capacity : 3500-4000 BPH
Error Range:  1%
Filling volume range : 1L-5L
Pneumatic air-operated source: 0.6Mpa clean and Stably compressed air -- 0.5M3/min
Machine Weight : 630kg
Machine Dimension : 2000mm x 1000mm x 2400mm

2016-10-07

semi automatic lotion liquid filling machine digital gear pump mineral oil filling machinery


How to setting time for one head gear pump mineral oil filling machinery
Controled by micro-computer, fill liquid by setting the filling time and speed.
Filling Liquid From 3-3000ml very precisely.
Digital Panel, very easy to operate.
Technical Parameter of semi automatic lotion liquid filling machine:
Voltage: AC 180V-260V (pls leave a message if u need 110v machine )
Power: 30W
Filling Range: 3ml-3000ml
Max Flow Rate: 3.2L/min
Package Size: 280X250X160 (mm)
Weight: 5kgs
Max Suck Distance: 2meter
Anti-dripping Funtion: Available
Memory Function out of power: Available
Interior diameter of filling nozzle: 5mm
Lotion Gear Pump Digital Filler Characteristics:
1. Import single-chip microcomputer control, high efficiency, low power consumption
2. Automatic counting function, effectively control filling quantiy
3. LCD display, touch screen is very easy to operate
4. High filing accuracy
5. Wide Voltage range
6. Working performance is stable and can be used for long time
7. This can self-suck the liquid.
8. The pump can stand acid and alkali
9. Anti-dripping design.
10. Reasonable design, made of stainless steel, meet GMP requirement
semi automatic lotion liquid filling machine panel function:
Filling time : for adjusting the filling time
Waiting time : waiting time between each filling when the machine is filling automatically .
Counter : filling counter
Filling speed : adjusting the speed
Fiilling machine controller : for adjusting the filling range . When you turn on the machine , push the button "setting" When the filling range reaches what you want , push the button "setting" once again .The machine will keep the filling range in memory .
Operation instruction:
1, turn on the machine ,and put the bottle under the filling head
2, push the button "setting". When the filling reaches the range you want , push the button "setting" once again . Then the machine will keep the filling range in memory .
3, push the button "auto ", and it will work automatically . Push the button "manual", and it will work manually .
4, the warranty of the machine is 1 year .
The pump is diaphragm pump and is consumable . When you find the filling turns slow, please change the pump .
Our digital pump filling machine has 1 head, 2 heads,3head,4head and 6heads:
2 nozzles pump digital filler
Three head gear pump filler
Four head Lotion Gear Pump Digital Filler
Six head digital filler
Packaging & Delivery
1, Packaging Detail: standard export wooden case package or carton.
2, Leading time: 1-3 days
3, Delivery time: depend on ways of shipping
Shipping & payment
1,ways of shipping:
1) Small machine will shipped by express (DHL, EMS, FedEx and so on) or air
2) Big order and big machine shipped by sea (FOB Shenzhen/CIF)
2, payment methods
We accept LC, TT, West Union , Papal or MoneyGram



2016-09-10

mineral water bottle filling machine price small juice filling machine manual filling machine



mineral water filling machine price use for small plant to filling liquid such as mineral water, cooking oils, juice, detergent.
This liquid filling machine using pump and self suck water to bottle through tube,which two nozzles height adjustable.
More detail of this model email to sales@topcnfilling.com

Labels

6 heads filling machine (1) Abfuellmaschine fuer Fluessigkeit (1) aluminum foils (1) automatic-filling-machinery (1) bag filling machine (1) beauty (1) bottle (1) capper (1) capping (1) caps (1) containers (1) customer (1) detergent shampoo (1) edible oil filling machine (1) equipment (1) filler (3) filler equipment (1) filling (1) filling capping (1) filling capping labeling line (1) filling capping labeling packaging lines,TSFM Semi Auto Filling Machine (1) filling machine (2) filling machine for honey (1) filling machine honey bottles (1) Filling Machine Line,filling machine (1) filling machine operate (1) filling machine with different nozzles (1) Filling Machines (1) finished product (1) Gear Pump Digital Filler (1) gear pump filling machinery (1) hand washing (1) honey (1) honey bottles (1) internet (1) lip gross (1) lip oil (1) liquid (1) liquid filling equipment, small packaging machine,self suction filler,filler,vertical filler,semi automatic filler (1) liquid filling machine (1) Liquid Filling Systems (1) liquid package machine (1) liquid-filling-machines (1) lotion filling machine (1) Manual+Bottle+Filling+Machine (1) manufacturers (1) máquina de llenado (1) máquina de llenado miel (1) mineral water (1) nozzles (1) oil (1) oil filling machinery (1) operation (1) packaging machine (1) PAFM Automatic Filling Machine (2) Perfume (1) pharma cosmetic food (1) Piston (1) rotary (3) sauce paste (1) screw capping machinery (1) seal (1) sealing (1) semi auto liquid filling machine (1) semi automatic (1) shampoo (1) small filler (1) small filling (1) solid powder (1) stand up bag spout filling machine (1) syrup (1) syrup.filling machine for liquid (1) treatment (1) TSFM Semi Auto Filling Machine (3) vacuum filling machine (2) water purifier (1) wave liquid (1)
